Selecting the correct ground reinforcement grid is a specification decision, not a cosmetic one. The wrong grid will deform, migrate or fail under load, regardless of how well it is installed.
The EcoGrid range is designed to cover everything from footpaths and gardens through to HGV turning zones and logistics yards. Each grid has a defined role, tested load capacity and intended surface type.
This guide explains how to choose the right EcoGrid for the job.
Core EcoGrid Range
These grids cover most domestic, commercial and infrastructure projects.
EcoGrid E30, Pedestrian and Light Duty
Used for footpaths, cycle routes, gardens and emergency escape routes.
With a 30 mm cell height, E30 is designed for pedestrian loading where ground protection and grass reinforcement are required, not vehicle traffic.
EcoGrid E40, Driveways and Parking
The most commonly specified grid for domestic driveways and car parks.
The 40 mm depth provides stability for cars and vans, and it is compatible with gravel and resin bound finishes. XXL panels reduce joints and speed installation.
EcoGrid E50, Heavy Duty Straight Runs
Used where heavier vehicles travel in straight lines.
E50 is suited to HGV access roads, lay-bys and large vehicle parking areas. It is often paired with BLOXX or E80 in higher stress zones.
EcoGrid E80, Heavy Turning Areas
Designed for sustained turning forces.
This grid is specified for logistics yards, HGV turning circles and airfield access areas where standard grids would distort under lateral load.
EcoGrid BLOXX, Decorative Hybrid System
A hybrid grid designed to accept concrete, stone or rubber inserts.
BLOXX connects directly to E50 and is used where visual finish and load performance are both required, such as car parks and utility areas.
Equestrian and Agricultural Grids
These grids address ground stability in environments where moisture, movement and impact are constant.
EcoGrid TR40, Riding Arenas
Designed to manage moisture within arena surfaces.
TR40 retains water within the grid structure, helping control dust and maintain consistent footing.
EcoGrid TP40, Agricultural and Stable Areas
Used in paddocks, stables, wash bays and farm access routes.
TP40 is resistant to impact, animal traffic and washdown conditions.
EcoGrid X30, Sub Base Stabilisation
Used beneath finished surfaces rather than as a visible layer.
X30 stabilises weak sub bases and protects excavations during construction, supporting long term performance above.
How to Select the Correct Grid
Grid selection should always be based on three factors:
- Traffic type, pedestrian, cars, vans, HGV straight runs or turning
- Surface finish, grass, gravel, resin, concrete or hybrid
- Ground conditions, weak sub grades, moisture or movement risk
Choosing based on appearance alone is the most common cause of grid failure.
Summary
EcoGrid systems are not interchangeable. Each grid is designed for a specific loading and movement profile.
From pedestrian paths to logistics yards, selecting the correct grid at design stage avoids rutting, migration and premature failure. When specified correctly, EcoGrid provides stable, permeable surfaces with predictable long term performance.
