450 x 450mm Block Paving Recessed Manhole Cover 10 Tonne

450 x 450mm Block Paving Recessed Manhole Cover 10 Tonne

Clear Opening: 450mm x 450mm
Tray Depth: 100mm
External Dimensions: 556mm x 556mm x 106mm

Recessed manhole cover designed for block paving, slabs and deeper infill build-ups. Suitable for patios, driveways and paved areas where a flush finish is required.

The 100mm tray depth allows for thicker paving construction, making it suitable for raised levels or installations with increased build-up.

£129.44
£129.44
Tax included. Shipping calculated at checkout.

Hurry up! Only 10 items in stock.

EG4545/100

Expected delivery date:
30 May Estimated arrival via standard delivery within 2–3 working days. Express delivery 1–2 working days available.

450 x 450mm Block Paving Recessed Manhole Cover 10 Tonne

450 x 450mm Block Paving Recessed Manhole Cover 10 Tonne

Description

This block paving recessed manhole cover is designed for installations where a larger clear opening and deeper infill are required. The recessed tray allows paving materials to be installed within the lid so the finished surface remains level and visually consistent.

With a 10 tonne load rating, it is suitable for domestic driveways and areas with occasional light vehicle traffic. The structural load is transferred through the galvanised steel frame into the surrounding ground, preventing the infill material from taking load.

The 100mm tray depth is suited to thicker paving systems, including raised patios or installations with deeper bedding and sub-base layers. Selecting a deeper tray helps avoid weak infill and ensures the finished surface aligns correctly with surrounding levels.

This cover is non-sealed and intended for external use only. It should not be used in internal environments or where water or odour sealing is required.

Key Features

  • 10 tonne load rating suitable for domestic driveways and light vehicle traffic
  • 100mm tray depth supports deeper paving and construction build-ups
  • Larger 450 x 450mm clear opening allows improved access to chambers
  • Recessed lid enables a continuous paving finish across the surface
  • Galvanised steel construction provides durability in external conditions
  • Frame transfers load into surrounding structure, not through the infill
  • Suitable for raised patios and areas with increased build-up depth
  • Lift-out cover allows access for inspection and maintenance

Material Composition

Manufactured from galvanised steel to provide structural strength and resistance to corrosion in typical external ground conditions. Suitable for general outdoor use but not for aggressive or chemically exposed environments.

Product Specifications

Product type: Block paving recessed manhole cover
Suitable location: External
Clear opening: 450mm x 450mm
Overall frame size: 556mm x 556mm
Tray depth (recess depth): 100mm
Frame depth: 106mm (excluding fixing lugs)
Material: Galvanised steel
Finish: Galvanised
Seal type: None
Locking: No
Load rating: 10 tonne
Lifting method: Lifting key points
Fixings supplied: No
Weight: Not specified
Standards: FACTA AAA, BS EN material and galvanising references
Options: Bespoke sizes available

Block Paving Recessed Manhole Covers

About this collection

Block Paving Recessed Manhole Covers

Block paving manhole covers are recessed access covers designed so block paving or patio slabs can be installed within the lid. They provide a flush finish and are commonly used over inspection chambers in patios, driveways and paved areas.

View Collection

FAQs

See All

What is the benefit of a 450 x 450mm clear opening?

It provides increased access compared to smaller covers, making inspection and maintenance easier, especially on deeper chambers.

Why choose a 100mm tray depth?

It suits thicker paving build-ups or raised levels. It is commonly used where standard 50–60mm trays are not deep enough.

Is this suitable for driveway use?

Yes. It is rated to 10 tonnes and suitable for domestic driveways with light vehicle traffic.

Can this be used indoors?

No. This is a non-sealed cover and should only be used externally.

Does the paving inside the tray support the load?

No. The frame carries the load and transfers it into the surrounding structure. The infill is for finish only.
